KW Coilovers are a very popular option for suspension on the 86 platform. Get your ride track ready with KW's suspension offerings!

The KW Clubsport coilovers combine KW's high-end racing technology with maintenance-free KW OEM components and part certificate.

This will provide you the ideal product to take full potential of your sports car during track days, sports car driving clinics, enthusiast drives on Grand Prix circuits and on tracks such as the Nürburgring Nordschleife.

The KW V3 Clubsports and KW V4 Clubsport provides the user numerous adjustment settings. This allows you to dial the suspension setup to your driving style and to adjust or match the tire/wheel setup of the vehicle. Depending on the vehicle, we also offer Clubsport suspensions in an inverted monotube design. In this case, the piston rod is on the bottom. This inverted design provides more precise steering and greater stability and safety. This is especially beneficial for cars that are exposed to high lateral forces on the track.

Rebound and compression dampening is independently adjustable by hand via the integrated click adjusters. Adjustable top mounts are optional on certain applications.

KW V3 Clubsport Racing Technology

The rebound adjuster knob provides 16 precise clicks to personally dial in your desired vehicle setup. Thus allowing you the possibility to influence wheel/tire loads or take into concern chassis characteristics. Independent from rebound adjustment is the compression dampening, 12 precise adjustment clicks are provided to adjust the low-speed dampening. Most notably used to dial in wheel/tire setup.

These adjustment features allow the user to dial in vehicle weight, wheel/tire combinations, various road surfaces and environmental conditions.

• independently adjustable rebound and compression damping technology
• stainless steel technology
• continuous lowering
• tested adjustment range
• high-quality components for a long-term durability
• adjustable rebound damping with 16 precise clicks
• adjustable compression damping with 12 precise clicks
• unique, independent damping force adjustment
• optional spherical bearing aluminum top mounts

Setup: Application and damper settings

The KW V3 Clubsport coilovers provide the ideal adjustment range for race tracks such as the Nürburgring Nordschleife and other racing circuits.

Features:

• Customized lowering
• Adjustable rebound (low speed)
• Adjustable compression stage (low speed)
• Composite spring seat
• Trapezoidal thread
• TUV certified

Install Instructions and Setup Guide

KW Install

KW Setup
